Category: Cellular Processes





Introduction



All cells come from other cells. New cells are formed during cell division which involves both the replication of the cell’s nucleus and division of the cytoplasm. The two kinds of cellular division are mitosis and meiosis. Mitosis usually makes body cells, somatic cells. Mitosis is used in adult cells for asexual reproduction, regeneration, and the maintenance and repair of body parts. The process called meiosis makes gametes, sperm and eggs, and spores in plants. Gamete or spore cells have half the chromosomes that the parent cell has.

Mitosis is the first of the cell divisions studied in this lab. It is easily observed in cells that are growing at a fast paces such as whitefish blastula or onion root tips, which are used in this lab. The onion root tips have the highest percentage of cells going through mitosis. The whitefish blastula is formed directly after the egg is fertilized. This is a period of a fast paced growth and numerous cellular divisions where mitosis can be observed. Just before mitosis the cell is in interphase, a part of the cell cycle where the cell has a distinct nucleus and nucleoli. Next is prophase, where the chromatin thickens into distinct chromosomes and the nuclear envelope breaks open releasing them into the cytoplasm. The first signs of the spindle apparatus begin to appear. Next the cell begins metaphase, where the spindle attaches to the centromere of each chromosome pair and moves them to the middle of the cell. This level position is called the metaphase plate. Then anaphase begins when the chromatids are separated and pulled to the opposite poles. The final stage is telophase where the nuclear envelope is reformed and the chromosomes gradually uncoil. Cytokinesis then may occur forming a cleavage furrow and then the two daughter cells will separate.

Meiosis is more complex and involves two nuclear divisions. The two divisions are called Meiosis I and Meiosis II. These two divisions result in the production of four haploid gametes. This process allows increased genetic variation due to crossing over where genes can be exchanged. The process, like mitosis, depends on interphase to replicate the DNA. Meiosis begins with prophase I. In this stage, homologous chromosomes move together to form a tetrad. This is where crossing over occurs resulting in the recombination of genes. Metaphase I moves the tetrads to the metaphase plate in the middle of the cell, and anaphase I reduces the tetrads to their original two stranded form and moves them to opposite poles. Telophase I then prepares the cell for its second division. Meiosis II is just like mitosis except that the daughter cells are haploid instead of diploid. DNA replication does not occur in interphase II, and prophase II, metaphase II, anaphase II, and telophase II occur as usual. The only change is the number of chromosomes.



Hypothesis



Mitosis is easily observed in the whitefish blastula and the onion root tip. Meiosis and crossing over occurs in the production of gametes, in animals, and spores, in plants.



Materials



Lab 3A. 1

The materials used in this lab are as follows: light microscopes, prepared slides of whitefish blastula and onion root tips, pencil, and paper.

Lab 3A. 2

The materials used in this lab are as follows: light microscopes, prepared slides of onion root tips, paper, and pencil.

Lab 3B. 1

The materials used in this section of the lab are as follows: a chromosome simulation kit, pencil and paper.

Lab 3B. 2

The materials used in this section of the lab are as follows: light microscopes, prepared slides of Sordaria fimicola, pencil, and paper.



Methods



Lab 3A. 1

Observe prepared slides of whitefish blastula and onion root tips under the 10X and 40X objectives. Sketch and identify each section of cell division.

Lab 3A. 2

Observe every cell and determine what stage the cell is in. Count at least 200 cells total, separating them into groups of the same phase. Consider it takes 24 hours for the onion root-tip cells to complete the cell cycle.

Lab 3B. 1

Use the lab book to show how to make the chromosomes. The simulation kit has plenty of beads to use. There are red and yellow beads to be used to show the different chromatids. There is also a piece that resembles half of a centromere which has a magnet to connect to another one.

Lab 3B. 2

Use a light microscope to observe the prepared slide and record all data.

Results

Lab 3A. 1

The sketches below show the phases of mitosis for the onion root-tip.





The sketches below show the phases of mitosis for the whitefish blastula.



Why is it more accurate to call mitosis “nuclear replication” rather than “cellular division”?



In mitosis, two new nuclei are formed and the cytokinesis is just part mitosis.



Explain why the whitefish blastula and onion root tip are selected for a study of mitosis.



The blastula is generally a ball of cells that are rapidly going under mitosis. The onion root-tip is an area where mitosis also occurs very rapidly.

Lab 3A. 2

The table below shows the data collected for this lab.



If your observations had not been restricted to the area of the root tip that is actively dividing, how would your results have been different?



There would have been less cell division since most of the plant’s growth occurs at the root-tip.



Based on the data in the table above, what can your infer about the relative length of time an onion root-tip cell spends in each stage of cell division?



The most time of an onion root-tip cell’s life is in interphase. Prophase is the next most common phase that the cells spend in.

Lab 3B. 1



List three major differences between the events of mitosis and meiosis.



Mitosis has only one nuclear division while meiosis has two. Mitosis also makes two diploid cells and meiosis makes four haploid cells. Crossing over is also only found in meiosis.



Compare mitosis and meiosis with respect to each of the following:





How are Meiosis I and Meiosis II different?



Meiosis I ends in two chromosomes with two chromatids and Meiosis II ends in four chromosomes with only one chromatid.



How do oogenesis and spermatogenesis differ?



Oogeneis forms the eggs and spermatogenesis forms the sperm.



Why is meiosis important for sexual reproduction?



Meiosis makes the chromosome number come out in half so that fertilization can come back and restore the diploid number.

Lab 3B. 2



Draw a pair of chromosomes in MI and MII, and show how you would get a 2:4:2 arrangement of ascospores by crossing over.





Error Analysis



No errors were reported in this lab but there could have been. The cells in Lab 3A. 1 could have been miscounted or not counted.



Conclusion



From the data collected in this experiment, it can be concluded that the mitotic stages of the whitefish blastula and the onion root-tip can be observed with a light microscope. The time spent in each phase of mitosis can be recorded and it is concluded that the most time spent in a stage is in interphase. It can also be concluded that the least time spent in a stage is in telophase. It is also understood that someone can simulate meiosis using a chromosome simulation kit. On the last part of the lab, Lab 3B. 2, one could conclude that more asci do not cross over than do the number of asci that do cross over.





Introduction:



All new cells come from previously existing cells. New cells are formed by karyokinesis- the process in cell division which involves replication of the cell’s nucleus and cytokinesis-the process in cell division which involves division of the cytoplasm. Two types of nuclear division include mitosis and meiosis. Mitosis typically results in new somatic, or body, cells. Mitotic cell division is involved in the formation of an adult organism from a fertilized egg, asexual reproduction, regeneration, and maintenance or repair of body parts. Meiosis results in the formation of either gametes in animals or spores in plants. The cells formed have half the chromosome number of the parent cell.

Mitosis is best observed in cells that are growing at a rapid pace, such as in the whitefish blastula or onion root cell tips. The root tips contain a special growth region called the apical meristem where the highest percentage of cells are undergoing mitosis. The whitefish blastula is formed immediately after the egg is fertilized, a period of rapid growth and numerous cell divisions where mitosis can be observed.

There are several stages included in before, during, and following mitosis. Interphase occurs right before a cell enters mitosis. During interphase, the cell will have a distinct nucleus with one or more nucleoli, which is filled with a fine network of threads of chromatin. During interphase, DNA replication occurs. After duplication the cell is ready to begin mitosis. Prophase is when the chromatin thickens until condensed into distinct chromosomes. The nuclear envelope dissolves and chromosomes are in the cytoplasm. The first signs of the microtubule-containing spindle also begin to appear. Next the cell begins metaphase. During this phase, the centromere of each chromosome attaches to the spindle and are moved to the center of the cell. This level position is called the metaphase plate. The chromatids separate and pull to opposite poles during the start of anaphase. Once the two chromatids are separate, each is called a chromosome. The last stage of mitosis is telophase. At this time, a new nuclear envelope is formed and the chromosomes gradually uncoil, forming the fine chromatin network seen in interphase. Cytokinesis may occur forming a cleavage furrow that will form two daughter cells when separated.

Meiosis is more complex than mitotic stages and involves two nuclear divisions called Meiosis I and Meiosis II. They result in the production of four haploid gametes and allow genetic variation because of crossing over of genetic material. Prior the process, interphase replicates the DNA. During prophase I, the first meiotic stage, homologous chromosomes move together to form a tetrad and synapsis also begins. This is where crossing over occurs, resulting in the recombination of genes. In Metaphase I, the tetrads move to the metaphase plate in the middle of the cell as on mitotic metaphase. Anaphase I brings the tetrads back to their original two stranded form and moves them to opposite poles. During Telophase I, the centriole is finished and the cell prepares for a second division. In Meiosis II, in Prophase II, centrioles move to opposite ends of the chromosome group. In Metaphase II, the chromosomes are centered within the center of each daughter cell. Anaphase II involves the centromere of the chromatids separating. Telophase II occurs when the divided chromosomes separate into different cells, known as haploid cells.

Sordaria fimicola, an ascomycete fungus, can be used to demonstrate the results of crossing over during meiosis. It spends most of its life haploid and only becomes diploid when the fusion of the mycelia of two different strains results in the fusion of two different types of haploid nuclei to form a diploid nucleus. Meiosis, followed by mitosis, in Sordaria results in the formation of eight haploid ascospores contained within a sac called an ascus. They are contained in a perithecium, a fruiting body, until mature enough to be released. The arrangement of spores directly reflects whether or not crossing over occurred. If an ascus has four tan ascospores in a row and four black ascospores in a row -4:4 arrangement, then no crossing over has taken place. If the asci has black and tan ascospores in sets of two -2:2:2:2 arrangement, or two pairs of black ascospores and four tan ascospores in the middle -2:4:2 arrangement, then crossing over has taken place.



Hypothesis:



The stages of mitosis can be examined in whitefish blastula and onion root cell tips by using a microscope. The process of crossing over and the stages of meiosis only occur during the creation of gametes and spores.



Materials:



Exercise 3A

The materials necessary for this exercise are a light microscope, prepared slides of whitefish blastula, onion root cell tips, pencil, and paper.

Exercise 3B

For this portion of the lab, materials needed are a bag of color-coded connecting beads and magnetized “centromeres,” several trays, and labels marked interphase, prophase, metaphase, anaphase, and telophase.



Methods:



Exercise 3A.1: Observing Mitosis

During this experiment, prepared slides of whitefish blastula and onion root tips should be observed under the 10X and 40X objectives of a light microscope. A cell in each stage of mitosis should be identified and sketched.

Exercise 3A.2: Time for Cell Replication

In this section of the lab, use the highest power objective on the microscope to observe and count every cell in the field of view. The cells should be counted according to the stage of mitosis they are in. At least 200 cells and 2 fields of view should be examined and counted. The percentage of cells in each stage is then recorded and the amount of time spent in each phase is calculated.

Exercise 3B.1: Simulation of Meiosis

For this portion of the experiment, a chromosome simulation kit will be used to demonstrate meiosis. Two sets of two strands with each set a different color, are connected to simulate DNA replication in both of the homologous pairs, the stage called interphase. Next, the chromosomes were entwined to represent synapsis in the stage known as prophase. Sections of beads were entwined between the pairs as in crossing over and aligned at the equator. Beads of each pair exchange places, representing metaphase. Next, anaphase was simulated by the homologous pairs being separated to opposite sides of the tray, or in terms of the “chromosomes,” the cell. Pushing the chromosomes into two separate cells, or trays, mimicked telophase.

Meiosis II was simulated as well. Prophase II is shown by the separation of the two beads, but no true change. The chromosomes again move to the equator during metaphase II, and in anaphase II, the two chromatids are separated and moved to opposite poles. Telophase II separates the chromosomes into four different cells.

Exercise 3B.2: Crossing Over during Meiosis in Sordaria

Prepared slides of Sordaria fimicola were observed under a light microscope. The asci were identified as either 4:4 or asci showing crossover. These readings were recorded. The percentage of each and map units were calculated.



Results:



Exercise 3A



Whitefish Blastula

Onion Root Cell Tips





Why is it more accurate to call mitosis “nuclear replication” rather than “cellular division”? It is more accurate to describe mitosis as “nuclear replication” because the cell does not divide in any of the mitotic steps. The entire process of mitosis is a series of steps that divides the nucleus into two separate nuclei at opposite poles. When a cell is truly split, the process is known as cytokinesis.



Explain why the whitefish blastula and onion root tips are selected for a study of mitosis. The blastula is what is formed directly following fertilization and, therefore, the cell is growing and many of the phases can be seen at this time. Onion root tip cells are also specimens that include a large amount of cell growth and a high percentage of cells experiencing mitotic activities.



Table 1: Number of Cells in Each Stage of Mitosis and Amount of Time Spent in Each Stage





If your observations had not been restricted to the area of the root tip that is actively dividing, how would your results differ? The majority of the cells would be in the stage of interphase and the results would be more difficult to gain and inaccurate.



Based on the data in Table 3.1, what can you infer about the relative length of time an onion root-tip cell spends in each stage of cell division? Prophase is the longest stage of mitosis (though Interphase, which occurs prior mitosis, takes up the most time of the cell’s life). Then, based on the data gained, the time spent in each stage decreases as you go further along.



Exercise 3B



List three major differences between the events of mitosis and meiosis. In mitosis, the nucleus divides once, and in meiosis, the nucleus is divided twice. Mitosis produces two identical daughter cells and meiosis produces up to four different cells. Synapsis and crossing over do not take place in mitosis, but do in meiosis.



Compare mitosis and meiosis with respect to each of the following.

Table 2: Comparing Mitosis and Meiosis







How are Meiosis I and Meiosis II different? Meiosis I begins with a tetrad and separates the homologous pairs. Meiosis II separates the two sister chromatids into haploids.



How do oogenesis and spermatogenesis differ? Oogenesis produces egg cells and spermatogenesis produces sperm cells.



Why is meiosis important for sexual reproduction? In meiosis the chromosome number is reduced to n so that it can be fertilized and void of any related (fertilized 2n) defects. Crossing- over occurs during meiosis, allowing for variations in the organisms created.



Table 3: The Number of Crossovers and Non-Crossovers



Number of 4:4	Number of Asci Showing Crossover	Total Asci	% Asci Showing Crossover Divided by 2	Gene to Centromere Distance (Map Units)
59	68	127	26.8%	(1)



2. Draw a pair of chromosomes in MI and MII, and show how you would get a 2:4:2 arrangement of ascospores by crossing over.

Error Analysis:



Because the results gathered in the lab were based mostly on observations and sketching, chances of error are slim. However, when counting the number of cells in specific stages in Exercise 3A, mistakes could have occurred. When identifying these stages in Exercise 3A, mistakes were also possible.



Discussion and Conclusion:



The stages of mitosis were observed and timed in Exercise 3A. These stages are prophase, metaphase, anaphase, and telophase. Prophase is the most time-consuming phase, while anaphase is the least time-consuming. Mitosis is just one portion of a cell’s life. The longest time of a cell’s life (73% to be exact) is spent in interphase, a phase just prior to prophase. During this phase, DNA replication takes place. Prophase involves the first signs of cell division with a thickening of the chromatin threads until the chromatin is condensed to chromosomes. In metaphase the chromosomes move to the center of the spindle and the centromere attaches to the spindle. During anaphase the chromatids are separated and moved to opposite ends of the poles. The final stage, telophase, involves the condensation of the chromosomes and the formation of a new nuclear envelope. Following telophase, cytokinesis may occur and the cytoplasm will be divided into two cells.

During the first section of Exercise 3B, the stages of meiosis were simulated using magnetic beads and centromeres with trays serving as the “cell.” Crossing over in Sordaria was observed using a microscope in the second portion of Exercise 3B. Using the information, the map units were then determined. The distance of the gene relative to the centromere in the Sordaria was 26.8 map units.



AP Biology: Chapter 6



METABOLISM & ENZYMES



1. Define the following terms:

a. Catabolic pathway ________________________________________________________

b. Anabolic pathway _________________________________________________________

c. Kinetic energy ____________________________________________________________

d. Potential energy __________________________________________________________

2. The First Law of Thermodynamics is the principle of… _______________________________

___________________________________________________________________________

___________________________________________________________________________

3. The Second Law of Thermodynamics involves changes in… __________________________

___________________________________________________________________________

___________________________________________________________________________

4. What is meant by a change in free energy? ________________________________________

___________________________________________________________________________

5. Compare reactions that are…

a. Exergonic _______________________________________________________________

________________________________________________________________________

b. Endergonic ______________________________________________________________

________________________________________________________________________

6. Sketch the ATP cycle:





7. How does ATP “couple reactions”? ______________________________________________

___________________________________________________________________________

___________________________________________________________________________

8. Sketch the profile of an exergonic reaction.





9. How do enzymes affect the energy profile? ________________________________________

___________________________________________________________________________

10. Define activation energy. ______________________________________________________

___________________________________________________________________________

11. Why are enzymes said to be specific? ____________________________________________

___________________________________________________________________________

___________________________________________________________________________

12. List factors that influence the rate of enzyme reactions. ______________________________

___________________________________________________________________________

___________________________________________________________________________

13. Label the diagram of the catalytic enzyme cycle.

14. How do competitive and noncompetitive inhibitors differ in their enzyme interactions?

___________________________________________________________________________

___________________________________________________________________________

15. What happens during allosteric regulation? ________________________________________

___________________________________________________________________________

___________________________________________________________________________

16. Describe feedback inhibition. ___________________________________________________

___________________________________________________________________________

___________________________________________________________________________

17. Define enzyme cooperativity. ___________________________________________________

___________________________________________________________________________

___________________________________________________________________________



AP Biology: Chapter 9



RESPIRATION — GLYCOLYSIS



1. Identify some specific processes the cell does with ATP. _____________________________

___________________________________________________________________________

___________________________________________________________________________

2. Explain why ATP is such a “high energy” molecule. __________________________________

___________________________________________________________________________

___________________________________________________________________________

3. Sketch the ATP cycle:





4. How does ATP “couple reactions”? ______________________________________________

___________________________________________________________________________

___________________________________________________________________________

5. What is the name of enzymes which phosphorylate molecules? ________________________

6. Define each of the following:

a. Oxidation _______________________________________________________________

________________________________________________________________________

b. Reduction _______________________________________________________________

________________________________________________________________________

7. What is the role of NAD+ & FAD+2 in respiration? ___________________________________

___________________________________________________________________________

___________________________________________________________________________

8. Explain why respiration is considered exergonic. ____________________________________

___________________________________________________________________________

___________________________________________________________________________

9. Glycolysis starts with _____________________ and produces _________________________

10. The Kreb’s cycle takes place in the: ______________________________________________

11. Pyruvate is converted to ___________________________________ before the Krebs cycle.

12. The Electron Transport Chain is located in the: _____________________________________

13. Describe the role of the Electron Transport Chain. What happens to the electrons and H+?

___________________________________________________________________________

___________________________________________________________________________

___________________________________________________________________________

14. What is chemiomosis and how is it generated?

___________________________________________________________________________

___________________________________________________________________________

___________________________________________________________________________

15. How does the mitochondrion generate ATP?

___________________________________________________________________________

___________________________________________________________________________

16. Label the diagram. Include: CO2, organic compounds, O2, H2O, respiration, photosynthesis, light, heat, ATP

23. Write the summary equation for cellular respiration:

___________________________________________________________________________

a. Where did the glucose come from? ___________________________________________

b. Where did the O2 come from? _______________________________________________

c. Where did the CO2 come from? ______________________________________________

d. Where did the H2O come from? ______________________________________________

e. Where did the ATP come from? ______________________________________________

f. What else is produced that is not listed in this equation? ___________________________

24. What was the evolutionary advantage of the proto-eukaryotes that engulfed aerobic bacteria

but did not digest them?

___________________________________________________________________________

___________________________________________________________________________

___________________________________________________________________________

25. Why do we eat? _____________________________________________________________

___________________________________________________________________________

___________________________________________________________________________

26. Why do we breathe? __________________________________________________________

___________________________________________________________________________

___________________________________________________________________________



17. What happens to most of the energy released during cell respiration? ___________________

___________________________________________________________________________

___________________________________________________________________________

18. Alcoholic fermentation converts glucose to ________________________________________

19. Alcoholic fermentation is utilized by what organisms? ________________________________

20. Lactic acid fermentation converts glucose to________________________________________

21. Lactic acid fermentation is utilized by what organisms? _______________________________

22. Identify examples of each of the following feedback mechanisms

a. Negative feedback ________________________________________________________

________________________________________________________________________

b. Positive feedback _________________________________________________________

________________________________________________________________________



AP Biology: CHAPTER 12

CELL CYCLE



1. What is meant by the concept that cells go through a cell cycle?

__________________________________________________________________________

__________________________________________________________________________

2. What are the key roles of cell division?

__________________________________________________________________________

__________________________________________________________________________

3. What is the significance of chromosome replication?

__________________________________________________________________________

__________________________________________________________________________

4. Sketch and label replicated chromosomes.





5. List the phases of the cell cycle with a brief description of what occurs in each phase.

a. _______________________________________________________________________

b. _______________________________________________________________________

c. _______________________________________________________________________

d. _______________________________________________________________________

e. _______________________________________________________________________



6. Label the stages and key features of each stage.

7. How does the spindle apparatus distribute chromosomes to the daughter cells?

__________________________________________________________________________

__________________________________________________________________________

8. What is the role of the kinetochores and the microtubules?

__________________________________________________________________________

__________________________________________________________________________

9. How does cytokinesis differ in animal and plant cells? Label the diagrams below.

__________________________________________________________________________

__________________________________________________________________________

__________________________________________________________________________

10. Eukatyotic mitosis is thought to have evolved from _________________________________

11. Why is the regulation of the cell cycle critical to normal cells?

__________________________________________________________________________

__________________________________________________________________________

12. What is the G1 checkpoint and where does it fit into the cycle?

__________________________________________________________________________

__________________________________________________________________________

13. What evidence is there that regulation is chemical in nature?

__________________________________________________________________________

__________________________________________________________________________

__________________________________________________________________________

14. Identify the role of the following in the cell cycle clock:

a. Kinase _________________________________________________________________

__________________________________________________________________________

b. Cyclin _________________________________________________________________

__________________________________________________________________________

c. CDKs _________________________________________________________________

__________________________________________________________________________

15. Describe the mechanism for regulating the passage of the cell into anaphase.

__________________________________________________________________________

__________________________________________________________________________

16. Describe what triggers mitosis from G2.

__________________________________________________________________________

__________________________________________________________________________

17. What is the role of ubiquitin?

__________________________________________________________________________

__________________________________________________________________________

__________________________________________________________________________

18. Describe a model for an external signal for growth.

__________________________________________________________________________

__________________________________________________________________________

__________________________________________________________________________

19. What happens when cancer develops?

__________________________________________________________________________

__________________________________________________________________________

__________________________________________________________________________

__________________________________________________________________________

20. What is the role of p53?

__________________________________________________________________________

__________________________________________________________________________

__________________________________________________________________________
